Compact-class 14V cordless impact driver with 1/4" hexagonal chuck for medium-duty work

  • Feature: Other
  • Chuck type: 1/4" hexagonal
  • No load RPM: gear 1: 1000 rpm; gear 2: 1500 rpm; gear 3: 2500 rpm

Technical Data

Feature
Other
Chuck type
1/4" hexagonal
No load RPM
gear 1: 1000 rpm; gear 2: 1500 rpm; gear 3: 2500 rpm
Maximum torque
50 Nm (1); 100 Nm (2); 150 Nm (3) 1
Full hammering frequency
3100 impacts/minute
Number of gears
3
Dimensions (LxWxH)
151 x 81 x 228 mm
Tool body weight
0.95 kg
A-weighted emission sound pressure level
83 dB (A) 2
Tri. vibr. val. for impact tightening of fasteners at max. cap. of tool (ah)
7.4 m/s²
Rated voltage
14.4 V
  1. Do not use the tool for applications where an exact torque or maximum torque is specified - there is a risk of over-tightening and damaging the screw or workpiece.
  2. According to the applicable product standard (see the Operating Instruction for more details)

Documents

Features & Applications

Features

  • High-efficiency brushless motor means the tool lasts longer and gets more work done per charge
  • Three gears and electronic speed control for easy switching between different driving speeds
  • Ergonomic grip and trigger for maximum comfort and convenience during long periods of use
  • Four bright LEDs around the chuck provide direct illumination of the work surface
  • 4 LEDs around the chuck illuminate the work surface for a good view of the task at hand

Applications

  • Driving HUS screw anchors up to 6mm in masonry and concrete
  • Driving 8 mm and 10 mm HRD frame anchors in masonry and concrete
  • Driving lag bolts up to 8mm in wood
  • Driving Spax screws up to 10 mm in wood
  • Driving self-drilling and self-tapping screws up to 4.8 mm in steel

For approval or certificate information, please see individual items.
